Brand: Nangong, Model: NGPT03-12/26-4S, Load capacity: 3 tons, Panel size: 2.6*1.2 meters, Net weight: 730KG, Color: blue;

Detailed parameters of 3-ton flatbed trailer:

1. The carrying capacity of this vehicle is 3 tons. The cargo area measures 2.6 meters in length, 1.25 meters in width, and approximately 0.6 meters in height. The main frame is constructed with 8-gauge steel, and the main beam is a welded composite beam. The deck is covered with 4mm checkered plates. Both the front and rear of the vehicle are equipped with 600mm high plug-in detachable guardrails, while no guardrails are required on the left and right sides;

2. The tires are four 500-8 solid tires, with a single wheel load capacity of 1.2 tons. It adopts a two-axle design and has a speed of 15KM/H;

3. The turntable is a 3-ton standard 180-degree rotary table, equipped with a 3-ton standard traction frame that can be adjusted up and down for fixation. Different vehicles can be easily adjusted for traction. A connecting device is installed at the rear of the vehicle to enable continuous traction;

4. Steel-connected frame, capable of making a 180-degree turn in place with a minimum turning radius;

5. Color: Blue, with yellow warning stripes sprayed around the edges;

6. Each unit is equipped with one dedicated connector and one plug pin.

3-ton flatbed trailers with detachable front and rear guardrails are produced by Nangong Vehicles all year round. They can be customized according to customer requirements for non-standard orders. They feature strong carrying capacity, low cost, and long service life.

Application: The flatbed trailer is unpowered and can be towed by forklifts or tractors. It is suitable for short-distance turnover transportation of bulk goods within factory areas, docks, ports, warehouses, and other similar locations.
